Electric Component
MERGE 9-14
Chapter 9
Motor installation
Back to the removal steps.
NOTE:
Match the marking line during motor installation.
Removal of bulb of headlight and front turn
signal light
1. Take out the key from the key switch.
2. Apply the parking brake.
3. Turn Tow/Run switch to TOW.
Please refer to Chapter 1 “Protection for
Electrical Safety”.
4. Disconnect the connecting wire of the headlight
and the cable plug-in package;
5. Remove the 4 screws fixing the headlight with a
Philips driver;
6. Remove the headlight; pull apart the power cord
from the headlight bulb;
7. Remove the 2 screws fixing the bulb with a screw
driver and take out the headlight bulb;
8. Turn the lamp receptacle of the front turn signal
light and remove the turn signal lamp bulb;
9. Check the bulbs of the headlight and the turn
signal lamp for continuity and replace the part in
case of un-continuity.
Headlight installation
