Driving Axle
EMERGE 6-2
Chapter 6
Removal of the Driving Axle
1. Park the vehicle on level ground.
2. Lift the rear body with the lifting jack before
putting a suitable bracket under the frame.
Refer to Chapter 1 "Use of Designated Lifting
Jack".
3. Wedge blocks onto the front lower part of the
front wheels.
4. Disconnect:
All the connecting lines of the electric motor.
5. Remove:
· Six bolts of the electric motor
· Electric motor
Refer to Chapter 9 "Removal of Motor".
6. Put an oil tray under the differential gear,
unscrew the bleeding bolt to discharge all the
lubricating oil in the differential case.
7. Remove:
· Wheel nut (of rear wheel)
· Rear wheel
To Next Page
