Body
MERGE 4-6
Chapter 4
· Edging fender
· Anti-slip pedal
Install:
In the reverse order of the removal procedures
Tightening the torque of steering wheel nuts：
50N·m (36.9ft·1b)
Removal of the Rear Cover
Remove:
1. Remove:
· Seat cushion
· Seat backrest
· Pillar
NOTICE:
Refer to "Removal of Seat Cushion" on page 4-3.
Refer to "Removal of Pillar" on page 3-2.
2. Remove:
· Rear box cover
· Rubber nail
· Screw
· Rear tray
Refer to "Removal of Rear Tray" on page 4-1.
3. Disconnect:
· Rear light connecting line
To Next Page
