Steering System
EMERGE 8-1
Chapter 8
Steering system
1、steering wheel 2、cover of steering cover 3、nut of steering wheel
4、bearing 5、inner snap ring 6、steering shaft
7、outer snap ring 8、protective sleeve of steering shaft 9、turn signal stalk
10、protective sleeve for wire harness 11、block of steering column
12、bolt 13、bolt 14、nut 15、universal joint spline
16、spline bearing of universal joint 17、dustproof cover of universal joint 18、nut
19、lock washer 20、 flat washer 21、steering gear housing 22、nut
23、outer snap ring 24、tape 25、dustproof cover 26、adjusting nut
27、adjusting cap 28、stress spring 29、hold downs 30、oil seal
31、small gear bearing 32、inner snap ring 33、outer snap ring 34、dustproof cap
35、bearing 36、bushing 37、steering rod 38、gear
39、stopple washer 40、dustproof sleeve 41、ball joint 42、slotted nut
43、cotter pin 44、nut 45、t
ape
