Tomberlin 2010 E-Merge - Front Bumper Removal; Rear Tray and Bumper Removal

Body
MERGE 4-1
Chapter 4
1. Removal of the Front Bumper
Remove:
· Bolt
· Front bumper
2. Removal of the Rear Tray
Remove:
· Rear box cover
· Rubber nail
· Screw
· Rear tray
· Clamping nut
3. Removal of the Rear Bumper
Remove:
· Bolt
· Rear bumper bracket
· Bolt
· Rear bumper
Install:
· Front bumper
In the reverse order of the removal procedures
Tightening torque：
63N·m (46.5 ft·1b)
