Front Axle
EMERGE 5-2
Chapter 5
Removal of the Front Axle
Remove
1. Park the vehicle on level ground.
2. Apply the parking brake.
3. Loosen: (front wheel) nuts
4. Lift up the front wheels with lifting jack.
Refer to Chapter 1 "Uses of Lifting Jack".
5. Remove:
· (Front wheel) nut
· Front wheel
6. Inspect:
· The operation (of wheel bearing）
Rotate the hub connected plate by hand
In case of unsmooth operation, the bearing is
to be replaced with new one.
7. Inspect:
· Free gap (of wheel bearing)
Swing the hub back and forth. In case the free
gap is too large, the slotted nut is to be
tightened. In case the clearance is still too
large, the bearing is to be replaced with new
one.
