Tomberlin 2010 E-Merge - Periodic Lubrication Plan

Regular Inspection and Adjustment
MERGE 2-3
Chapter 2
Periodic Lubrication Plan
Periodic lubrication plan
Normal intervals Maintenance
Lubricated
points
Recommend lubricating oil
Brake pedal shaft 1 3# Lithium based grease
Parking brake 2 3# Lithium based grease
Accelerator pivot bar foot 3 3# Lithium based grease
Charger receptacle 4 NYE760G
Front suspension 5 3# Lithium based grease
Front stub axle 7 Lithium based grease
The user or trained
technician applies the
lubricating oil once a
quarter (every 50
working hours)
Braking grease cup 8 DOT3 （3000）brake oil
Inspect the driving axle/oiled
cork position.
6
32.8 ounce（1.1 liter），37OZ
lubricating oil (GL - 5)
The trained
technician applies the
lubricating oil once a
year (every 100
working hours)
Inspect the front-wheel
bearing (Remount when
necessary).
7 3# Lithium based grease
