Overview
MERGE 1-5
Chapter 1
• To avoid unintentional start-up of the electric
vehicle, please turn the Tow/Run switch to the
TOW position before disconnecting or
connecting the battery.
• After disconnection of the battery, please wait for 90
seconds to allow for the discharge of the capacitor
in the controller.
NOTICE:
After removing or replacing the wire, please arrange
and fix the wiring and wiring harness. Inappropriate
arrangement of the wiring and wiring harness may
result in the malfunction of the vehicle, property
damage and/or personal injury and death.
Use the Designated Lifting Jack
Front: put the lifting jack below the pivot to support it.
Rear: Use the portion of crossed frames.
Caution:
In the case that the lifting jack is placed behind the
vehicle, the lifting jack should be prevented from
touching the back tower bar.
First, remove the
positive electrode
cable
Disconnect the
storage battery
cable here
To Next Page
