Driving Axle
EMERGE 6-9
Chapter 6
Removal of the Differential Gear
1．Remove:
· Differential gear
· Fixing bolt of differential gear
· Bottom cover of differential gear
Caution
The bottom cover of the differential gear should
be pried up by a flat-head screwdriver. Please
note not to damage the sealing surface of the
box or deform the bottom cover of the
differential gear.
2．Remove:
· Bearing pressing block bolt
· Bearing pressing block②
· Differential with ring gear ① and bearing ③
