Body
MERGE 4-8
Chapter 4
Rear cover
1. Rear cover 2. Rear cover plate 3. Rear box cover
4. Tray 5. Left rear light 6. Right rear light
7. On-board charging plug box 8. Left ventilating window 9. Right ventilating window
10. Lower hinge 11. Rubber nail 12. Screw
13. Nut 14. Large pan-head bolt 15. Nut
16. Screw 17. Rubber nail 18. Rubber cover of rear pillar
