Body
MERGE 4-3
Chapter 4
· Rear seat backrest bracket ④
· Backrest ⑤
Install:
· Front seat backrest
· Tightening the torque of bolt:
22N·m (16.2 ft·1b)
· Rear seat backrest （2+2 series）
· Tightening the torque of bolt:
22N·m (16.2 ft ·1b)
· Seat cushion
· Bottom plate of seat cushion
· Bolts on seat cushion bottom plate
· Handrail bracket
· Handrail bracket fixing bolt
Tightening torque：
22N·m (16.2 ft ·1b)
To Next Page
