Front Axle
EMERGE 5-4
Chapter 5
12. Remove:
· Brake disc bolt
Tightening torque
23N·m (17.0 ft·1b)
· Brake disc
Standard thickness of brake disc
4 mm (0.16 in)
Maximum wearing thickness
1 mm (0.04 in)
13. Remove:
· Bolt
Tightening torque
23N·m (17.0 ft·1b)
· Fore wheel brake shoe
Standard thickness
7 mm (0.28 in)
Maximum wearing thickness
1 mm (0.04 in)
14. Inspect:
· Spindle free gap
Swing the Spindle. In case the free gap is fairly
large, the inside spacer and bush of the
Spindle are to be replaced.
