PREPARATIONS
SETTING THE INTERNAL FIXATION TARGET
In setting of the internal fixation target, fixation target on/flicker status and fixation
target pattern can be set.
Switching of internal fixation target on/flicker
The internal fixation target can be switched between on and flicker states.
When shipped, "FLICKERING" (flicker) is set.
1 Move the cursor to "FIXATION TYPE" on the "MAIN MENU" screen, and
press the to call out the "FIXATION TYPE"
screen.
2 Press the or and select
"CONSTANT" (on) or "FLICKERING" (flicker).
3 Press the ; the setting is done and the "MAIN
MENU" screen returns.
Switching of internal/external fixation target (option)
You can change the internal/external fixation target.
When shipped, "INTERNAL" (internal fixation target) is the default setting.
1 Move the cursor to "INTERNAL/EXTERNAL FIX" on the "MAIN MENU"
screen and press the to access the "INTER-
NAL/EXTERNAL FIX" screen.
2 Press the or and select
"INTERNAL" (internal fixation target) or "EXTERNAL" (external fixation tar-
get).
3 Press the ; the setting is done and the "MAIN
MENU" screen is reset.
