SPECIFICATIONS AND PERFORMANCE
SPECIFICATIONS AND PERFORMANCE
SPECIFICATIONS
1)
Split line working range
* The design as well as the specifications are subject to change without prior notice.
ELECTROMAGNETIC COMPATIBILITY
This product conforms to the EMC standard (IEC 60601-1-2 : 2001).
ELECTRIC RATING
Except Europe
Source voltage : AC 100,120V, 220, 240V 50/60Hz
Power input : 80VA (nomal), 400VA (max)
Europe
Source voltage : AC 110, 120, 230, 240V, 50/60Hz
Power input : 80VA (nomal), 400VA (max)
Picture angle 45°, Digital zoom is possible. (×2/×4)
Working range 40.7mm
Minimum pupil diameter φ4.0mm or more when 45° is set. φ3.7mm or more when the digital zoom is
set.
Diopter compensation range No compensation lens
*1)
-13D ~+12D
Using (-) compensation lens -12D ~-33D
Using (+) compensation lens +9D ~+40D
Fixation target Center : 4 fixed points
Nose : 1 fixed point Ear : 1 fixed point
Automatic detection of right-and-left movement
Base movement Coarse: back-forth 46mm, right-left 100mm
Fine: back-forth & right-left 16mm each
Vertical: 30mm
Chinrest movement Vertical: 60mm
Power supply, consumption Power voltage General type AC100, 120, 220, 240V ±10%
European type AC110, 120, 230, 240V ±10%
Switch over by selector switch
Power frequency: 50/60Hz
Power consumption 80VA(normal), 400VA(max.)
Leak current Ground: Normal 0.5mA max., Single failure 1mA max.
Exterior: Normal 0.1mA max., Single failure 0.5mA max.
Patient: Normal 0.1mA max., Single failure 0.5mA max.
Dimensions 272(W)×505(D)×530-560(H) (instrument body)
Weight 24kg (instrument body)
