Toshiba BMS-CT2560U-E - Set the screen brightness; Set power consumption control conditions

Touch Screen Controller Owner's Manual
80
-EN
You can set the brightness of the screen and the duration after the end of the operation. In (1, 3, 10, 30, 60, 360 (6 hours),
720 (12 hours) minutes)
You can set the conditions for controlling power consumption peaks.
Based on the pulse signal from the pulse oscillation type watt hour meter, the power usage is calculated, and if it exceeds the
power usage threshold, an operation control signal is sent to the outdoor unit.
There are two different settings:
• Energy threshold: Controls operation based on the pulse signal from the pulse oscillation type watt hour meter.
• Peak cut signal reception: Controls operation based on the signal from the external demand device.
System diagram
Set the screen brightness
1 Tap [1-(2)] with [1-(1)] (P.69)
2 Select the brightness and tap [2-(1)]
Set power consumption control conditions
1
-(2)
1
-(2)
1
-(1)
1
-(1)
2
-(1)
2
-(1)
Pulse oscillation type watt
hour meter
Energy threshold
Peak cut signal reception
System
Controller
Power peak cut
signal when
[Threshold] is
exceeded
External demand device
Outdoor unit
Pulse signal
