5
1 Product Overview
1-1. Function list
*1Conditions for PC connection (operating environment)
OS: Windows 10
LAN port: 10BASE-T or 100BASE-TX wired LAN port
Other: mouse/keyboard, printer (if printing is required)
Specifications
Detailed specifications
Power supply 220-240 V AC 50/60 Hz
Consumed current 1.17 A
Operating temperature/
humidity range
0°C to 40°C, 10% to 90% RH (no dew condensation)
Dimensions (mm) H136×W205×D10(+80) (Embedded dimensions shown in parenthesis)
Mass
1.34 kg (Touch Screen Controller)
0.45 kg (power adapter)
LCD
Type 7 TFT liquid crystal, 800×480, 167,000 colours
(Luminance 800 cd/m
2
, contrast ratio 600:1)
Touch Screen Projection-capacitive type
Communication ports
· RS-485 port ×1
(for connecting four digital I/O interfaces and four watt hour meter interfaces)
· LAN port ×1 (for connecting PC)
USB port USB memory stick connection port ×2
External contact input 8 inputs
External contact output 4 inputs
Included PC software
(Requires a separate PC (*1))
· Remote Control Software
· Energy Report Software
· Section Configuration Software
