Toshiba TECRA A11 Series User Manual

1 Hardware Overview
1-4 TECRA A11/S11/P11/Satellite Pro S500 Series Maintenance Manual (960-784) [CONFIDENTIAL]
Figures
Figure 1-1 Front of the computer........................................................................................... 10
Figure 1-2 System unit configuration.................................................................................... 11
Figure 1-3 System unit block diagram................................................................................... 13
Figure 1-4 3.5-inch FDD (USB External).............................................................................. 18
Figure 1-5 2.5-inch HDD....................................................................................................... 19
Figure 1-6 DVD Super Multi drive........................................................................................ 23
Figure 1- 7 Keyboard............................................................................................................. 25
Figure 1- 8 LCD module........................................................................................................ 26
Tables
Table 1-1 3.5-inch FDD specifications.................................................................................. 18
Table 1-2 2.5-inch HDD specifications ................................................................................. 19
Table 1-3 2.5-inch HDD specifications ................................................................................. 21
Table 1-4 DVD-ROM drive specifications............................................................................ 22
Table 1-5 DVD Super Multi drive outline dimensions.......................................................... 24
Table 1-6 LCD module specifications................................................................................... 27
Table 1-7 Power supply output rating.................................................................................... 29
Table 1-8 Battery specifications ............................................................................................ 31
Table 1-9 Time required for charges ..................................................................................... 32
Table 1-10 Data preservation time......................................................................................... 33
Table 1-11 RTC battery charging/data preservation time ..................................................... 33
Table 1-12 AC adapter specifications.................................................................................... 34

Toshiba TECRA A11 Series Specifications

General

RAM	Up to 8GB DDR3
Operating System	Windows 7 Professional
Battery Life	Up to 4 hours
Optical Drive	DVD SuperMulti Drive
LAN	Gigabit Ethernet
Processor	Intel Core i3, i5, or i7
Display	15.6-inch HD (1366x768)
Storage	HDD up to 500GB
Graphics	Intel HD Graphics
Wireless	802.11 a/g/n
Webcam	Integrated webcam
Ports	USB 2.0, VGA, RJ-45
Card Reader	SD
Battery	6-cell Li-ion
Dimensions	374 x 250 mm
Chipset	Mobile Intel QM57 Express Chipset
