TECRA A11/S11/P11 Satellite Pro S500 Series Maintenance Manual (960-784) [CONFIDENTIAL] 4-39
4.12 3G card
Removing the 3G card
To remove the 3G card, follow the steps below and refer to Figure 4-22.
1. Disconnect the 3G antenna cables from the connectors on the 3G card using an
antenna coaxial cable disconnector.
2. Remove the following screws securing the 3G card.
3. Disconnect the 3G car the system board.
ï‚· M2.0ï‚´3C BIND screw ï‚´2
d from the connector on
Figure 4-22 Removing the 3G card
M2.0x3C BIND
3G card
3G antenna cable (blue)
3G antenna cable (red)
