1 Hardware Overview
TECRA A11/S11/P11/Satellite Pro S500 Series Maintenance Manual (960-784)[CONFIDENTIAL] 1-3
Chapter 1 Contents
Chapter 1 Hardware Overview......................................................................................... 1
1.1 Features......................................................................................................................... 5
1.2 System Unit Block Diagram....................................................................................... 13
1.3 3.5-inch Floppy Disk Drive (USB External) .............................................................. 18
1.4 2.5-inch Hard Disk Drive............................................................................................ 19
1.5 Optical Drive (ODD) .................................................................................................. 22
1.5.1 DVD-ROM Drive.................................................................................. 22
1.5.2 DVD-Super Multi Drive........................................................................ 23
1.6 Keyboard..................................................................................................................... 25
1.7 TFT Color Display...................................................................................................... 26
1.7.1 LCD Module.......................................................................................... 26
1.8 Power Supply.............................................................................................................. 28
1.9 Batteries ...................................................................................................................... 31
1.9.1 Main Battery.......................................................................................... 31
1.9.2 Battery Charging Control...................................................................... 32
1.9.3 RTC battery........................................................................................... 33
1.10 AC Adapter................................................................................................................. 34

Toshiba TECRA A11 Series Specifications

General

RAM	Up to 8GB DDR3
Operating System	Windows 7 Professional
Battery Life	Up to 4 hours
Optical Drive	DVD SuperMulti Drive
LAN	Gigabit Ethernet
Processor	Intel Core i3, i5, or i7
Display	15.6-inch HD (1366x768)
Storage	HDD up to 500GB
Graphics	Intel HD Graphics
Wireless	802.11 a/g/n
Webcam	Integrated webcam
Ports	USB 2.0, VGA, RJ-45
Card Reader	SD
Battery	6-cell Li-ion
Dimensions	374 x 250 mm
Chipset	Mobile Intel QM57 Express Chipset
