4-86 [CONFIDENTIAL] TECRA A11/S11/P11 Satellite Pro S500 Series Maintenance Manual (960-784)
4 Replacement Procedures
1. Turn up the insulators (INSU ANT HLD L and INSU ANT HLD R) and release the
harnesses.
4.25 LCD unit
Removing the LCD unit
To remove the LCD unit, follow the steps below and refer to Figure 4-46 to 4-51.
Figure 4-46 Removing the LCD unit (1)
INSU ANT HLD R
INSU ANT HLD L
