TECRA A11/S11/P11 Satellite Pro S500 Series Maintenance Manual (960-784) [CONFIDENTIAL] 4-23
4.7 HDD
Removing the HDD
To remove the HDD, follow the steps below and refer to Figure 4-11 and 4-12.
CAUTION: Take care not to press on the top or bottom of a HDD. Pressure may cause the
data loss or damage to the device.
1. Remove the following screw securing the HDD cover.
 M2.55B FLAT HEAD screw 1
2. Insert your finger into the slot and lift the HDD cover to remove.
3. Remove the HDD assembly from the slot and disconnect it from the connector on the
system board.
Figure 4-11 Removing the HDD assembly
HDD cover
M2.55B FLAT HEAD
Slot
HDD assembly
Guide
Guide

Toshiba TECRA A11 Series Specifications

General

RAM	Up to 8GB DDR3
Operating System	Windows 7 Professional
Battery Life	Up to 4 hours
Optical Drive	DVD SuperMulti Drive
LAN	Gigabit Ethernet
Processor	Intel Core i3, i5, or i7
Display	15.6-inch HD (1366x768)
Storage	HDD up to 500GB
Graphics	Intel HD Graphics
Wireless	802.11 a/g/n
Webcam	Integrated webcam
Ports	USB 2.0, VGA, RJ-45
Card Reader	SD
Battery	6-cell Li-ion
Dimensions	374 x 250 mm
Chipset	Mobile Intel QM57 Express Chipset
