4-30 [CONFIDENTIAL] TECRA A11/S11/P11 Satellite Pro S500 Series Maintenance Manual (960-784)
4.9 Keyboard
Removing the Keyboard
T
CAUTION: As the keytop may fall out, when handling the keyboard always hold it by the
o remove the keyboard, follow the steps below and refer to Figure 4-16 to 4-19.
frame and do not touch the keytop.
1. Turn over the computer.
2. Open the display and make it flat.
3. Insert your fingers into the slit on both sides and remove the KB holder.
Figure 4-16 Removing the KB holder
KB holder
Slit
Slit
To Next Page
