TECRA A11/S11/P11 Satellite Pro S500 Series Maintenance Manual (960-784) [CONFIDENTIAL] 4-65
Figure 4-36 Removing the RGB harness/serial port unit
RGB harness
Serial port FFC
M2.5x5C Tapping
Insulator
M2.5x5B FLAT HEAD
(RGB SERIAL
INSULATOR
)
Serial port unit
TECRA A11/S11/P11 Satellite Pro S500 Series Maintenance Manual (960-784)
[CONFIDENTIAL] 4-65
