Toshiba TECRA A11 Series User Manual

TECRA A11/S11/P11 Satellite Pro S500 Series Maintenance Manual (960-784) [CONFIDENTIAL] 4-17
4.4 Memory module
Removing the Memory module
To remove the memory module, confirm that the computer is shut down. Then follow the
s
CAUTION: emory module, make sure the computer is powered off.
teps below and refer to Figure 4-6 and 4-7.
When removing the m
Removing a memory module with the power on might damage the module or
the computer itself.
Do not touch the connectors on the memory module or on the computer.
Dust and stains on the connectors may cause memory access problems.
Never press hard or bend the memory module.
1. Turn over the computer.
2. Loosen the screw fixing the memory cover.
3. Remove the memory cover.
Memory cover
Figure 4-6 Removing the memory cover
Screw

Toshiba TECRA A11 Series Specifications

General

RAM	Up to 8GB DDR3
Operating System	Windows 7 Professional
Battery Life	Up to 4 hours
Optical Drive	DVD SuperMulti Drive
LAN	Gigabit Ethernet
Processor	Intel Core i3, i5, or i7
Display	15.6-inch HD (1366x768)
Storage	HDD up to 500GB
Graphics	Intel HD Graphics
Wireless	802.11 a/g/n
Webcam	Integrated webcam
Ports	USB 2.0, VGA, RJ-45
Card Reader	SD
Battery	6-cell Li-ion
Dimensions	374 x 250 mm
Chipset	Mobile Intel QM57 Express Chipset
