Toshiba TECRA A11 Series - LCD Module; TFT Color Display

1 Hardware Overview
1.7 TFT Color Display
The TFT color display consists of 15.6-inch HD /HD+ LCD module.
1.7.1 LCD Module
The LCD module used for the TFT color display uses a backlight as the light source and can
display a maximum of 16M colors with 1,366 x 768 or 1,600 x 900 resolutions.
Figure 1-8 shows a view of the LCD module and Table 1-6 lists the specifications.
Figure 1- 10 LCD module
1-26 TECRA A11/S11/P11/Satellite Pro S500 Series Maintenance Manual (960-784) [CONFIDENTIAL]
