4-16 [CONFIDENTIAL] TECRA A11/S11/P11 Satellite Pro S500 Series Maintenance Manual (960-784)
4.3.4 Smart Card
Removing the Smart Card
T
CAUTION: Insert or remove a Smart Card in accordance with any instructions in the
o remove the Smart Card, follow the steps below and refer to Figure 4-5.
Smart Card manual or the manuals of the computer system you are using.
1. Grasp the Smart Card and remove it.
Figure 4-5 Removing the Smart Card
he metal connectors facing up.
2. Push it carefully to ensure a firm connection.
Installing the Smart Card
To install the Smart Card, follow the steps below and refer to Figure 4-5.
1. Insert the Smart Card into the card slot with t
Smart Card
