TECRA A11/S11/P11 Satellite Pro S500 Series Maintenance Manual (960-784) [CONFIDENTIAL] 4-37
4.11 Wireless LAN card
Removing the Wireless LAN card
To remove the wireless LAN card, follow the steps below and refer to Figure 4-21.
1. Disconnect the wireless LAN antenna cables from the wireless LAN card (white
antenna coaxial
ess LAN card.
3. Disconnect the wireless LAN card from the connector on the system board.
cable from “A” or “1” and black cable from “B” or “2”) using an
cable disconnector.
2. Remove the following screws securing the wirel
M2.03C BIND screw 2
Figure 4-21 Removing the wireless LAN card
M2.0x3C BIND
Wireless LAN card
Wireless LAN antenna cable
To Next Page
