Toshiba TECRA A11 Series User Manual

Tests and Diagnostics
TECRA A11/S11/P11/Satellite Pro S500 Series Maintenance Manual (960-784) [CONFIDENTIAL] 3-97
3.34 . Windows PE T&D
3.34.1 Equipment Configuration for Test
The following table indicates equipment configuration necessary for conduction of the tests
items shown below using WinPE T&D.
Test Item Equipment required Remarks
USB USB flash memory Free space : More than 12MB (When you
start WinPE T&D from a USB memory,
use 512MB or more of USB memory.)
ODD Media containing test data The test data is included in a bootable CD.
File name: CDDTEST0.DAT
LAN Wired router, LAN cable The router has the DHCP server function
FDD USB connected FDD
2HD Floppy disk
Free space : 384KB
IEEE1394 IEEE1394-compatible
external HDD
Free space : More than 12MB
To execute the above test, start the machine after connecting all of the equipment
* In particular, if LAN router is connected after OS is activated, IP address is not assigned to
it.

Toshiba TECRA A11 Series Specifications

General

RAM	Up to 8GB DDR3
Operating System	Windows 7 Professional
Battery Life	Up to 4 hours
Optical Drive	DVD SuperMulti Drive
LAN	Gigabit Ethernet
Processor	Intel Core i3, i5, or i7
Display	15.6-inch HD (1366x768)
Storage	HDD up to 500GB
Graphics	Intel HD Graphics
Wireless	802.11 a/g/n
Webcam	Integrated webcam
Ports	USB 2.0, VGA, RJ-45
Card Reader	SD
Battery	6-cell Li-ion
Dimensions	374 x 250 mm
Chipset	Mobile Intel QM57 Express Chipset
