Tests and Diagnostics
3-154 [CONFIDENTIAL] TECRA A11/S11/P11/Satellite Pro S500 Series Maintenance Manual (960-784)
3.35.5 Task Function
This T&D has three tasks, each of which has the following function.
3.35.5.1 Log Utilities(Task #5)
This function logs error information generated while a test is in progress and stores the
results in RAM. This function can store data on a floppy disk or USB memory
.
The operation guide is displayed at the bottom of the screen and the error status names are
displayed on the right side of the screen.
The error information on the screen can be processed respectively with each key of the [1] to
[9] keys. In the case of error retry OK, "R" is added before the error status. However, the
error count is not incremented.
6:B-Read : FD Log Read
7:B-Write : FD Log Write
8:C-Read : USB Flash Memory Log Read
9:C-Write : USB Flash Memory Log Writefs
Note: Error logs can be saved to a FD or the USB flash memory with the name of
*ERRORLOG.TXT..
