Installing the Optical disk drive
To install the Optical disk drive, follow the steps below and refer to Figure 4-13 to 4-15.
1. When installing a new optical disk drive, set the OD tical disk drive
while securing the latches.
D bezel to the op
ODD bezel
Optical disk drive
Figure 4-15 installing the ODD bezel
2. Set the ODD rear bracket to the optical disk drive and secure them
following screws.
with the
bly with the following screw.
M2.55B FLAT HEAD screw 1
M2.03C BIND screw 2
3. Insert the optical disk drive assembly into the slot to connect it to the connector on
the system board and secure the optical disk drive assem
