4-28 [CONFIDENTIAL] TECRA A11/S11/P11 Satellite Pro S500 Series Maintenance Manual (960-784)
3. Remove the following screws and ODD rear bracket from the optical disk drive.
  BIND screw 2 M2.0 3C
Figure 4-14 Removing the optical disk drive
M2.03C BIND
ODD rear bracket
Optical disk drive
