Toshiba TECRA A11 Series User Manual

1 Hardware Overview
1-6 TECRA A11/S11/P11/Satellite Pro S500 Series Maintenance Manual (960-784) [CONFIDENTIAL]
 Chipset
Toshiba TECRA A11/S11/P11/Satellite Pro S500 Series computer is Equipped with Intel
Ibex peak QM57 or HM55.
 VGA Controller
The PC comes in with one of the following two types:
 The internal graphics controller in Intel Ibex peak is used.
 NVIDIA N10M-NE is used.
 HDD
The computer has a 2.5-inch SATA HDD. The following capacities are available.
 160/250/320 GB
 USB FDD
A 3.5-inch USB FDD accommodates 2HD (1.44MB) or 2DD (720KB) disks.
 Optical Drive
A DVD-ROM drive or DVD Super Multi drive (double layer) can be installed.
 Display
The PC comes in with one of the following two types:
 15.6”HD(1366x768) CSV or Non-CSV
 15.6”HD+(1600x900) Non-CSV
Interface
To external monitor via - RGB connector and mini display port
 Keyboard
An-easy-to-use 85(US)/87(UK)-key keyboard provides a numeric keypad overlay for fast
numeric data entry or for cursor and page control. The keyboard also includes two keys
that have special functions in Microsoft
®
Windows
®
7. It supports software that uses a
101- or 102-key enhanced keyboard.

Toshiba TECRA A11 Series Specifications

General

RAM	Up to 8GB DDR3
Operating System	Windows 7 Professional
Battery Life	Up to 4 hours
Optical Drive	DVD SuperMulti Drive
LAN	Gigabit Ethernet
Processor	Intel Core i3, i5, or i7
Display	15.6-inch HD (1366x768)
Storage	HDD up to 500GB
Graphics	Intel HD Graphics
Wireless	802.11 a/g/n
Webcam	Integrated webcam
Ports	USB 2.0, VGA, RJ-45
Card Reader	SD
Battery	6-cell Li-ion
Dimensions	374 x 250 mm
Chipset	Mobile Intel QM57 Express Chipset
