Tests and Diagnostics
3-50 [CONFIDENTIAL] TECRA A11/S11/P11/Satellite Pro S500 Series Maintenance Manual (960-784)
Subtest 04 Wireless communication Switch
This subtest checks if the Wireless communication switch works properly.
If the test is started with the switch ON, following message appears in the
display.
Wireless communication Switch is set to a start
position (OFF)
Slide the switch to OFF position. Then, following message appears in the
display.
Wireless communication Switch ON !!
Slide the switch to ON position. Then, following message appears in the
display.
Wireless communication Switch OFF !!
After Sliding the switch to OFF position, return to the ONLY ONE TEST
menu automatically.
Subtest 05 USB
NOTE: When executing this subtest, USB test module and USB cable must be connected.
This subtest checks if USB port works properly.
The following menu appears in the display.
#################################################################
######## USB Port Select (XXXXXXXXX) #######
#################################################################
* *
* 0 ............ Port 0 (Front in the right side ) *
* 1 ............ Port 1 (Behind the right side) *
* 2 ............ Port 2 (Left side) *
* 9 ............ EXIT *
* *
*****************************************************************
.... Press test number[0-2,9] ?
Connect the USB test module and USB cable to the computer.
Input the port test number and press Enter.
OK message appears in the display if the test ends without a defective.
