Tests and Diagnostics
TECRA A11/S11/P11/Satellite Pro S500 Series Maintenance Manual (960-784) [CONFIDENTIAL] 3-69
Check of the antenna connection
1. Confirm that the icon for wireless LAN appears at the lower right of the screen under
the circumstances the wireless LAN communication is available. (It is no problem if a
cross is shown on the icon.)
2. Double-click the icon. If the computer finds any AP (Access Point), the antenna
marks like as follows will appear. It shows the antenna cables are surely connected to
the wireless LAN card.
3. The following message will appear if the antenna cables are not connected to the
wireless LAN card or no available access point is found. In this case, check the
antenna cable connection to the wireless LAN card by disassembling the computer
following the steps described in Chapter 4, Replacement Procedures.

Toshiba TECRA A11 Series Specifications

General

RAM	Up to 8GB DDR3
Operating System	Windows 7 Professional
Battery Life	Up to 4 hours
Optical Drive	DVD SuperMulti Drive
LAN	Gigabit Ethernet
Processor	Intel Core i3, i5, or i7
Display	15.6-inch HD (1366x768)
Storage	HDD up to 500GB
Graphics	Intel HD Graphics
Wireless	802.11 a/g/n
Webcam	Integrated webcam
Ports	USB 2.0, VGA, RJ-45
Card Reader	SD
Battery	6-cell Li-ion
Dimensions	374 x 250 mm
Chipset	Mobile Intel QM57 Express Chipset
