Tests and Diagnostics
3-142 [CONFIDENTIAL] TECRA A11/S11/P11/Satellite Pro S500 Series Maintenance Manual (960-784)
3) Result judgment
When all the test items of a mouse test disappear and it is normal, Please push the "Pass"
button of a mouse test screen. Press the "Fail" button, when abnormal.
A warning message is displayed, when the "Pass" button is pressed before the mouse test
items 1-9 were all completed. The thing in which the operator made the mistake is told.
OK: Although the keyboard test is not ended, it is considered as success.
Cancel: It returns to a keyboard test screen.
When the item to the mouse tests 1-9 is eliminated, it becomes impossible moreover, to
choose the "Fail" button.
■ In the case of PASS
The PASS Count display on the test screen is zoomed in and (OK) is displayed in the Result
field on the WinPE T&D screen.
■ In the case of FAIL
The Error Count on the test screen is zoomed in and (NG) is displayed in the Result field
on the WinPE T&D screen.
