Tests and Diagnostics
3-164 [CONFIDENTIAL] TECRA A11/S11/P11/Satellite Pro S500 Series Maintenance Manual (960-784)
［ FDC Status ］
0 1 2 3 4 5 6
FDC Status
= XX XX XX XX XX XX
0 ： Result Status 0
1 ： Result Status 1
2 ： Result Status 2
3 ： Cylinder Address
4 ： Head Address
5 ： Sector Address
6 ： Number of Bytes / Sector
［ Result Status 0 ］
7 6 5 4 3 2 1 0
IC1 IC0 SE EC NR HD US1 US0
IC1／IC0 ： Interrupt Code bits
00＝normal，01＝abnormal，10＝invalid CMD
11＝abnormal（FDD ready）
SE ： Seek end
EC ： Equipment check (track 0 is detected)
NR ： Not ready
HD ： Head address
US1／US0 ： Unit select
