Tests and Diagnostics
3-172 [CONFIDENTIAL] TECRA A11/S11/P11/Satellite Pro S500 Series Maintenance Manual (960-784)
Physical Memory Capacity (MB) of memory which is installed in PC
NetWork0 Name of LAN card. Only the first LAN card is displayed on the
screen.
MAC address Mac address of LAN card
IDE HDD Name of the first IDE HDD and its capacity (GB)
IDE HDD Name of the second IDE HDD and its capacity (GB)
1394 Disk Name of HDD connected to IEE1394 and its capacity (GB)
USB Flash Disk Name of USB flash disk and its capacity (GB)
ODD0 Name of ODD and media type
FDD Name of FDD
Key Board Name of keyboard
Mouse Name of mouse
Other Disk Name of HDD other than IDE, IEEE1394 and USB and its capacity
3.36.1.2 Test conditions
The following table lists the test statuses.
Item Name Description
T&D Version Version of WindowsPE T&D
Test mode Indicates the test mode. When a test is performed in Multitask,
Multitask is displayed. When performed in Sequential, Sequential is
displayed.
CPU Stress If CPU stress is applied, Yes is displayed. If not applied, No is
displayed.
Limit pass count The number of passes of a test specified.
