TECRA A11/S11/P11 Satellite Pro S500 Series Maintenance Manual (960-784) [CONFIDENTIAL] 4-19
Installing the Memory module
To install the memory module, confirm that the computer is shut down. Then follow the steps
b
CAUTION: emory module, make sure the computer is powered off.
elow and refer to Figure 4-6 and 4-7.
When installing the m
Inserting a memory module with the power on might damage the module or
the computer itself.
Never press hard or bend a memory module.
1. Insert the memory module(s) into the connector(s) slantwise and press it to connect
CAUTION:
firmly.
When inserting a memory module to the slot B only, the power LED blinks
as followings.
The power LED blinks orange twice, white once and then repeats the same
blinking.
After installing the memory module, make sure that the memory module is
secured with the left and right latches.
2. Set the memory cover and secure it with the screw.
3. When the power of the computer is turned on, the computer checks
memory size. Confirm that the new memory is detected correctly.
automatically the
4. If the memory is not detected, check that it is connected correctly.

Toshiba TECRA A11 Series Specifications

General

RAM	Up to 8GB DDR3
Operating System	Windows 7 Professional
Battery Life	Up to 4 hours
Optical Drive	DVD SuperMulti Drive
LAN	Gigabit Ethernet
Processor	Intel Core i3, i5, or i7
Display	15.6-inch HD (1366x768)
Storage	HDD up to 500GB
Graphics	Intel HD Graphics
Wireless	802.11 a/g/n
Webcam	Integrated webcam
Ports	USB 2.0, VGA, RJ-45
Card Reader	SD
Battery	6-cell Li-ion
Dimensions	374 x 250 mm
Chipset	Mobile Intel QM57 Express Chipset
