TECRA A11/S11/P11 Satellite Pro S500 Series Maintenance Manual (960-784) [CONFIDENTIAL] 4-21
3. Remove the SIM card from the SIM card holder.
Figure 4-9 Removing the SIM card (2)
efer to Figure 4-8 and 4-9.
2. Lay the SIM card holder down and lock the SIM card release latch while sliding it
in the opposite direction as shown in the figure 4-8.
Installing the SIM card
To install the SIM card, follow the steps below and r
1. Set the SIM card into the SIM card holder.
SIM card
