TECRA A11/S11/P11 Satellite Pro S500 Series Maintenance Manual (960-784) [CONFIDENTIAL] 4-33
5. Lift the top edge of the keyboard while releasing the latches and turn the keyboard
face down on the palm rest.
6. Disconnect the keyboard flexible cable from the connector CN3230 on the system
board and remove the keyboard.
Figure 4-19 Removing the keyboard (3)
Keyboard
Keyboard flexible cable
CN3230
