4-54 [CONFIDENTIAL] TECRA A11/S11/P11 Satellite Pro S500 Series Maintenance Manual (960-784)
3. Remove the following screw securing the smart card holder.
4. Lift up the hook of the smart card holder in the direction as shown in the figure
below to remove the smart card holder from the slot.
ï‚· M2.5ï‚´5C Tapping screw ï‚´1
Figure 4-31 Removing the smart card holder
Smart card holder
Hook
M2.5x5C Tapping
