M2.0x4B BIND
M2.0x4B BIND
TECRA A11/S11/P11 Satellite Pro S500 Series Maintenance Manual (960-784) [CONFIDENTIAL] 4-75
Figure 4-39 Removing the fin/DC fan (external VGA model) (2)
Fan harness
Fin (with DC fan)
CN3380
