Appendices Appendix B Board Layout
B-2 [CONFIDENTIAL] TECRA A11/S11/P11/Satellite Pro S500 Series Maintenance Manual (960-784)
Table B-1 System board (FHNSY*) connectors and ICs (front)
Number Name
CN2110 PC CARD interface connector
CN2170 Smart Card interface connector
CN2600 PCI-E MINI CARD interface connector
CN3110 It is debugging port for development only
CN3230 KB interface connector
CN4440 Bluetooth interface connector
CN5300 LCD interface connector
CN6150 Speaker interface connector
CN6070 Int-Mic interface connector
CN9540 WebCam interface connector
CN9500 P-SW interface connector
IS2520 EXPRESSCARD interface connector
CN9530 FHNJK*/FHVJK* board interface connector
CN9550 FHNFS*/ FHVFS* board interface connector
CN9700 FELICA interface connector (6-pin) :Not used
