Appendices Appendix B Board Layout
B-4 [CONFIDENTIAL] TECRA A11/S11/P11/Satellite Pro S500 Series Maintenance Manual (960-784)
Table B-2 System board (FHNSY*) connectors and ICs (back)
Number Name
CN1400 Memory A connector
CN1410 Memory B connector
CN1900 SATA HDD interface connector
CN1910 2
nd
SDD interface connector (Not used)
CN1950 SATA ODD interface connector
CN1970 eSATA/USB interface connector
CN2300 DOCKING interface connector
CN4050 LAN interface connector
CN3010 MDC module interface connector
CN3011 MDC interface connector
J3010 Modem(RJ11) interface connector
CN4620 USB interface connector
CN3380 FAN interface connector
CN9510 RGB interface connector
CN5690 Displayport interface connector
CN9300 RTCVCC interface connector
CN8800 DC-IN interface connector
CN8810 Battery connector
CN9570 FHNSM*/FHVSM* board interface connector(Not used)
CN9520 Serial unit interface connector
IS1050 CPU
IC1600 Ibex Peak-M (chip set)
IS2140 MEDIA BRIDGE I/F connector
