Troubleshooting Procedures
TECRA A11/S11/P11/Satellite Pro S500 Series Maintenance Manual (960-784) [CONFIDENTIAL] 2-29
F116
S3 shift start
RAM
CN1400, CN1410 (RAM
Conn.)
F117 S4 shift start RAM
CN1400, CN1410 (RAM
Conn.)
F118 S5 shift start RAM
CN1400, CN1410 (RAM
Conn.)
F119
USB electric supply setting
start
PCH
EC
IC1600 (PCH)
IC3200 (EC/KBC)
F11A
Completion of a USB
electric supply setting
PCH
EC
IC1600 (PCH)
IC3200 (EC/KBC)
F11B Shutdown processing RAM
CN1400, CN1410 (RAM
Conn.)
F11C
Completion of Shutdown
processing
RAM
CN1400, CN1410 (RAM
Conn.)
F11D S3 return service start
BIOSROM
RAM
IC3000/IC3002 (BIOS
ROM), CN1400, CN1410
(RAM Conn.)
F1FF
End of S3 return processing.
Shifts to OS.
RAM
CN1400, CN1410 (RAM
Conn.)
NOTE: Status outputted by the test means the last error detected in the debug port test.
Check 1 If the D port is status F11Eh or F120h is displayed, go to “HDD Trouble shooting
Procedure in Section 2.6.
Check 2 If any other D port status error code is displayed, perform Procedure 3.
D port error code is as follows:
Error code Contents
F003h or F004h SC initialization error
F00Bh BIOS update error
F117h Exception check error
F121h Clock generator error

Toshiba TECRA A11 Series Specifications

General

RAM	Up to 8GB DDR3
Operating System	Windows 7 Professional
Battery Life	Up to 4 hours
Optical Drive	DVD SuperMulti Drive
LAN	Gigabit Ethernet
Processor	Intel Core i3, i5, or i7
Display	15.6-inch HD (1366x768)
Storage	HDD up to 500GB
Graphics	Intel HD Graphics
Wireless	802.11 a/g/n
Webcam	Integrated webcam
Ports	USB 2.0, VGA, RJ-45
Card Reader	SD
Battery	6-cell Li-ion
Dimensions	374 x 250 mm
Chipset	Mobile Intel QM57 Express Chipset
