Trane CSAA User Manual

Start-Up
134 CLCH-SVX07K-EN
Table 44. Back or top inlet low-flow Traq damper-air mixing and indoor economizer sections
Unit Size Part Number
Traq Damper
Size (in)
Damper
Type
Qty
Peak Velocity
(fpm)
Total Area
(ft
2
)
CFM @ 10VDC
Peak Velocity
L/s @ 10VDC
Peak Velocity
6 495100860001 13 Min. Outside Air 1 2475 0.92 2279 1076
8, 10 495100860001 13 Min. Outside Air 1 2475 0.92 2279 1076
12, 14, 17 495100870001 16 Min. Outside Air 1 2475 1.40 3455 1630
21, 25 495100890001 20 Min. Outside Air 1 2600 2.18 5671 2676
30, 35, 40 495100880001 24 Min. Outside Air 1 2600 3.14 8164 3853
50, 57 495100900001 28 Min. Outside Air 1 2600 4.27 11,112 5244
66 495100900001 28 Min. Outside Air 1 2600 4.27 11,112 5244
80 495100900001 28 Min. Outside Air 2 2600 8.54 22,224 10,488
100 495100900001 28 Min. Outside Air 2 2600 8.54 22,224 10,488
120 495100900001 28 Min. Outside Air 2 2600 8.54 22,224 10,488
Table 45. Mixing box Traq damper inlet - single-side standard flow
Unit size Part number
Traq damper
size (in) Qty
Peak velocity
(fpm)
Total area
(ft
2
)
CFM@10VDC peak
velocity
L/s@ 10VDC peak
velocity
3, 4, 6, 8 495100860001 13 1 2475 0.92 2279 1076
10, 12 495100870001 16 1 2475 1.40 3455 1631
14, 17 495100860001 13 2 2475 1.84 4559 2152
21, 25 495100870001 16 2 2475 2.79 6910 3262
30, 35, 40 495100890001 20 2 2600 4.36 11,341 5354
50, 57, 66 495100880001 24 2 2600 6.28 16,328 7708
80 495100900001 28 2 2600 8.59 22,225 10,492
100 495100900001 28 3 2600 12.82 33,337 15,738
120 495100880001 24 4 2600 12.56 32,656 15,417
Table 46. Mixing box Traq damper inlet - single-side low flow
Unit size Part number
Traq damper
size (in) Damper type Qty
Peak velocity
(fpm)
Total area
(ft
2
)
CFM@10VDC
peak velocity
L/s@ 10VDC
peak velocity
14, 17 495100860001 13 Min. Outside Air 1 2475 0.92 2279 1076
21, 25 495100870001 16 Min. Outside Air 1 2475 1.40 3455 1631
30, 35, 40 495100890001 20 Min. Outside Air 1 2600 2.18 5671 2677
50, 57, 66 495100880001 24 Min. Outside Air 1 2600 3.14 8164 3854
80 495100900001 28 Min. Outside Air 1 2600 4.27 11,112 5246
100 495100900001 28 Min. Outside Air 1 2600 4.27 11,112 5246
120 495100880001 24 Min. Outside Air 1 2600 3.14 8164 3854
