Trane CSAA User Manual

Start-Up
CLCH-SVX07K-EN 135
Table 47. Mixing box Traq damper inlet - dual-side standard flow
Unit size Part number
Traq damper
size (in) Qty
Peak velocity
(fpm)
Total area
(ft
2
)
CFM@10VDC peak
velocity
L/s@ 10VDC peak
velocity
3, 4, 6, 8 495100860001 13 2 2475 1.84 4559 2152
10, 12 495100870001 16 2 2475 2.79 6910 3262
14, 17 495100860001 13 4 2475 3.68 9118 4305
21, 25 495100870001 16 4 2475 5.58 13,820 6525
30, 35, 40 495100890001 20 4 2600 8.72 22,682 10,708
50, 57, 66 495100880001 24 4 2600 12.56 32,656 15,417
80 495100900001 28 4 2600 17.10 44,450 20,985
100 495100900001 28 6 2600 25.64 66,674 31,477
120 495100880001 24 8 2600 25.12 65,312 30,834
Table 48. Mixing box Traq damper inlet - dual-side low-flow
Unit size Part number
Traq damper
size (in) Damper type Qty
Peak velocity
(fpm)
Total area
(ft
2
)
CFM@10VDC
peak velocity
L/s@ 10VDC
peak velocity
3, 4, 6, 8 495100860001 13 Min. Outside Air 1 2475 0.92 2279 1076
10, 12 495100870001 16 Min. Outside Air 1 2475 1.40 3455 1631
14, 17 495100860001 13 Min. Outside Air 1 2475 0.92 2279 1076
21, 25 495100870001 16 Min. Outside Air 1 2475 1.40 3455 1631
30, 35, 40 495100890001 20 Min. Outside Air 1 2600 2.18 5671 2677
50, 57, 66 495100880001 24 Min. Outside Air 1 2600 3.14 8164 3854
80 495100900001 28 Min. Outside Air 1 2600 4.27 11,112 5246
100 495100900001 28 Min. Outside Air 1 2600 4.27 11,112 5246
120 495100880001 24 Min. Outside Air 1 2600 3.14 8164 3854
Table 49. Side inlet standard Traq dampers - diagonal economizer section
Unit size Part number
Traq damper
size (in) Quantity
Peak velocity
(fpm)
Total area
(ft2)
CFM@10VDC
peak velocity
L/s@10VDC peak
velocity
3 495100860001 13 1 2475 0.92 2279 1076
4, 6, 8 495100860001 13 2 2475 1.84 4559 2151
10, 12, 14 495100870001 16 2 2475 2.79 6905 3259
17 495100860001 13 4 2475 3.68 9118 4303
21 495100890001 20 2 2600 4.36 11,341 5352
25 495100870001 16 4 2475 5.58 13,820 6522
30 495100890001 20 3 2600 6.54 17,012 8028
35, 40 495100900001 28 2 2600 8.55 22,224 10,488
50 495100880001 24 3 2600 9.42 24,492 11,558
57 495100880001 24 4 2600 12.56 32,656 15,410
66 495100900001 28 3 2600 12.82 33,336 15,731
80 495100900001 28 4 2600 17.10 44,448 20,975
100, 120 495100900001 28 5 2600 21.37 55,561 26,219
