Dimensions and Weights
CLCH-SVX07K-EN 17
Unit size
3 4 6 8 10 12 14 17 21 25 30
Hoods
-Back inlet hood with
moisture eliminator airfoil
and Traq dampers
22.25 44.00 44.00 50.38 61.50 66.38 71.88 72.00 79.88 79.88 93.38
16.45 27.43 28.03 43.37 30.68 39.46 41.60 48.91 58.03 70.43 88.77
-Side inlet hood with
moisture eliminator airfoil
and Traq dampers
20.00 20.00 20.00 20.00 22.88 22.88 31.38 25.75 29.13 25.75 27.88
13.24 13.24 17.08 21.89 22.99 31.33 33.26 37.70 49.27 63.07 72.07
-Exhaust hood - airfoil
damper
20.00 20.00 20.00 20.00 22.88 22.88 31.38 25.75 29.13 25.75 27.88
12.36 12.36 15.95 20.47 21.26 29.08 29.65 34.70 45.03 58.67 67.02
-Economizer inlet hood with
moisture eliminator
45.50 49.00 49.50 48.00 53.00 53.00 56.50 52.00 62.50 57.00 62.50
40.42 31.13 38.02 52.31 58.30 64.42 133.62 170.43 174.54 208.64 217.75
- Inlet hood for motorized
impeller fan with economizer
22.11 22.11 27.86 27.86 33.61 33.61 36.36 37.49 39.99 39.49 45.11
28.89 31.26 43.31 50.62 57.44 63.94 71.40 86.45 100.87 121.19 135.13
-Exhaust hood for motorized
impeller fan with economizer
22.47 28.22 28.22 28.22 33.97 34.97 37.97 41.22 43.22 39.72 45.47
21.40 31.92 31.92 39.45 44.86 54.92 58.74 72.07 88.58 108.36 117.88
Pipe cabinet weight
15 in. long, 36 in. deep 104.00 104.00 116.00 120.00 120.00 127.00 127.00 141.00 148.00 164.00 164.00
24 in. long, 36 in. deep 122.00 122.00 135.00 140.00 140.00 147.00 147.00 162.00 170.00 187.00 187.00
48 in. long, 36 in. deep 169.00 169.00 184.00 191.00 191.00 200.00 200.00 218.00 228.00 249.00 249.00
96 in. long, 36 in. deep 263.00 263.00 284.00 293.00 293.00 305.00 305.00 331.00 343.00 373.00 373.00
Notes:
1
Nominal airflow is based on 500 fpm through a nominal coil (i.e. 500xunit size 8=4000 cfm).
2
Airflow@625 fpm through the flat filter (maximum
filter velocity).
3
Height includes standard 2.5-inch base frame for sizes 3-57 and 6-inch base frame for sizes 66-120.
4
Height includes 6-inch base
frame for sizes 3-120.
5
Variable lengths available from 14-96 inches.
6
Nominal length and height shown for discharge plenums. Variable plenum
height and length is available from 0.5 to 1.5 of nominal.
7
Fan section weights include the heaviest fan with the largest ODP motor available.
8
Access section required with humidifiers for dispersion distance.
9
Multizone weight does not include cooling coil on lower deck.
Table 5. Section dimensions (inches) and weights (pounds) — unit sizes 3 to 30 (continued)
