Dimensions and Weights
18 CLCH-SVX07K-EN
Table 6. Section dimensions (inches) and weights (pounds) - unit sizes 31-120
Nominal airflow
1
17,500 20,000 25,000 28,500 33,000 40,000 50,000 60,000
Airflow at 625 fpm
2
23,263 25,519 34,375 39,581 47,225 53,475 65,106 76,388
Unit size
35 40 50 57 66 80 100 120
Height - indoor unit
3
67.25 67.25 75.75 85.50 92.50 107.50 119.75 119.75
Width 100.00 112.50 125.50 125.50 140.50 140.50 154.50 182.00
Height for outdoor unit
includes base drip lip
4
75.00 75.00 84.38 94.13 97.63 112.63 124.88 124.88
Weight add for outdoor unit
(lbs/in. of unit length)
3.02 3.28 3.73 6.12 2.57 2.57 2.80 3.25
Access or blank
5
-Small horizontal
10.00 10.00 10.00 10.00
n/a n/a n/a n/a
211.11 227.92 254.69 265.35
-Medium horizontal
14.00 14.00 14.00 14.00 15.00 15.00 15.00 15.00
241.53 260.24 290.28 302.41 430.36 449.60 493.59 549.13
-Extended-medium
horizontal
19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00
279.57 300.64 334.76 348.74 476.36 497.88 545.85 605.56
-Medium-large horizontal
24.50 24.50 24.50 24.50 24.50 24.50 24.50 24.50
321.40 345.09 410.37 427.50 574.11 600.46 656.89 725.47
-Large horizontal or turning
48.00 48.00 48.00 48.00 49.00 54.00 60.00 60.00
514.42 557.22 639.24 682.26 907.93 1036.33 1242.40 1387.96
-Extra-large horizontal or
turning
63.75 63.75 68.50
n/a n/a n/a n/a n/a
624.86 675.12 809.42
-Ducted inlet or ducted
outlet section
10.00 10.00 10.00 10.00 10.00 10.00 10.00 10.00
211.10 227.90 254.70 265.30 372.90 389.30 428.30 478.60
Blender
48.00 48.00 48.00 48.00 49.00 54.00 60.00 60.00
540.76 593.46 675.51 731.75 970.30 1112.23 1345.03 1567.62
Cool Dry Quiet (CDQ)
Desiccant Dehumidification
56.00 56.00 59.00
n/a n/a n/a n/a n/a
2914.00 3122.00 4224.00
Coils
-Small horizontal
(with 4-row UW)
10.00 10.00 10.00 10.00
n/a n/a n/a n/a
690.59 754.61 934.27 1044.33
-Medium horizontal
(with 8-row UW)
14.00 14.00 14.00 14.00 15.00 15.00 15.00 15.00
1094.27 1219.78 1561.92 1759.58 2220.94 2558.94 3094.04 3638.44
-Extended-medium
horizontal (with 8-row UW)
19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00
1148.70 1279.06 1613.56 1813.06 2275.46 2615.73 3163.21 3712.02
-Medium-large horizontal
(with 10-row W)
24.50 24.50 24.50 24.50 24.50 24.50 24.50 24.50
1955.08 2216.68 2754.49 3215.01 3876.05 4488.82 5499.42 6713.50
-Large horizontal or vertical
(with 10-row W)
48.00 48.00 48.00 48.00
n/a n/a n/a n/a
2131.70 2401.84 2985.19 3454.40
Staggered Coils
Small horizontal
(with max rows largest coil)
49.00 51.50 54.50 54.50 n/a n/a n/a n/a
1239.16 1358.54 1740.02 1921.19 n/a n/a n/a n/a
Medium horizontal
(with max rows largest coil)
57.00 59.50 62.50 62.50 68.50 68.50 70.50 76.00
1629.33 1807.39 2337.91 2643.08 2834.74 3283.32 3740.49 4377.96
Extended-medium horizontal
(with max rows largest coil)
67.00 69.50 72.50 72.50 76.50 76.50 78.50 84.00
2519.67 2815.10 3050.80 3471.98 4156.92 4938.48 5672.92 6666.73
Medium-large horizontal
(with max rows largest coil)
n/a n/a 83.50 83.50 87.50 87.50 89.50 95.00
n/a n/a 3841.11 4311.87 5217.20 6253.55 7187.36 8426.40
