TDP-225 series

0~31

0~3

Note:

When in “SET HEAD OFF” mode, the function “SET GAP AUTO” doesn’t work even the printer head

is opened and closed, but it can work when power on the printer.

Example

The example below is operated in DOS environment via the parallel port connection to setup the

label size, gap distance and sensor sensitivity.

C:\>COPY CON LPT1<ENTER>

SIZE 4,2.5<ENTER>

GAP 0.12,0<ENTER>

SET GAP 1<ENTER>

C:\>

Note:

<ENTER> stands for keyboard “ENTER” key. In the above example, please press “ENTER” key

instead of typing <ENTER> in the above example. <CTRL> stands for keyboard “Ctrl” key.

Troubleshooting:

Press the FEED key to test. Does printer stop at the same position on each label without the error

light blinking? If not, adjust the setting to a larger number. When adjusting this setting, begin from 0

and then on to higher values incrementally.
